Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage

オンラインです

Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage

Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage
Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage

大画像 :  Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage

商品の詳細:
起源の場所: 中国
ブランド名: CHUQI
お支払配送条件:
最小注文数量: 1セット
パッケージの詳細: 木箱
受渡し時間: 60日
支払条件: T/T
供給の能力: 100セット

Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage

説明
圧力システム: 空気圧定圧制御 同期技術: 完全閉ループ電気同期
コア保証: 滑りゼロ、伸びゼロ 品質基盤: 絶対的に安定した圧力
制御精度: 高精度な速度追従 欠陥の除去: パターンの変形を防ぎます
システムの性質: 動的リアルタイム補償
ハイライト:

pneumatic belt embossing machine

,

precise synchronization embossing system

,

pattern slippage elimination embosser

Pneumatic Pressure Stabilization, Precise Synchronization – Embossing System that Eliminates Pattern Slippage
Product Introduction
This advanced embossing system ensures flawless pattern reproduction through two core technologies. The pneumatic pressure control system delivers gentle, stable, and precisely settable linear pressure, eliminating the fluctuations common in mechanical pressure systems to achieve uniform embossing depth. Combined with fully closed-loop electrical synchronization that tracks haul-off machine speed in real-time, the system achieves "zero speed difference" to completely eliminate pattern distortion, stretching, and slippage defects.
Main Specifications
  • Pressure Source: Clean, stable air supply equipped with precision pressure regulating valves, gauges, and stabilizing devices
  • Synchronization Control: Utilizes inverter master-slave control or servo synchronization systems
  • System Response: High response speed for real-time compensation of speed and pressure variations
  • Protection Mechanism: Features alarms and protective functions for over-pressure, pressure loss, and synchronization loss
  • Result Guarantee: Provides the foundation for high-quality continuous embossing of registered patterns and precision textures
Technical Parameters
Item Parameter / Description
Pressure Control Method Precision pneumatic control system
Synchronization Control Method Fully closed-loop electrical synchronization (Master-slave drive)
Pressure Control Precision ±0.05 MPa
Synchronization Precision ≤ ±0.1% speed following error
Air Supply Pressure Requirement 0.6 - 0.8 MPa
Control Signal Interface Analog/Digital (e.g., Pulse)
Frequently Asked Questions
Q: Is "pneumatic pressure stabilization" truly better than mechanical stabilization during long-duration operation?
A: Yes, the advantages are significant. Mechanical stabilization systems using springs can suffer from pressure decay or fluctuation due to fatigue and heat. Pneumatic systems use compressed air as the medium, allowing pressure to be precisely set via regulating valves and maintained constant, unaffected by running time. Additionally, air pressure possesses "elasticity" that automatically compensates for minor material thickness inconsistencies, resulting in softer, more uniform embossing effects particularly suitable for precise or soft materials.
